电源 DC24V,功耗 36W,排气压力 10MPa
驾驶时间 连续通电,间隔时间 没有限制
接线方法 DIN端子,保证润滑脂 L U B E特有油脂
馈电开关 是(可选),油脂液位开关 是(仅7C)
盖子 難燃樹脂(UL94-V0)
IP規格 取得,CE規格 取得泵排除空气 没有驾驶时间限制
使用渗透範囲 NLGI NO. 00. 0. 1
重量 7C 2.2kg、4C 2.1kg 2C 2.1kg、8P 3.3kg
3P 2.2kg |
Power DC24V,Power Consumption 36W,Discharge Pressure 10MPa
Driving time Continuous Energization,Stop time No Restriction
Connection Method DIN terminal,Guaranteed Grease Lube Original Grease
Feed switch Yes (optional),Grease level switch Yes (7C only)
Covers Flame retardant resin(UL94-V0)
IP standard Get,CE standard Get,Pump air removal Driving timeNo Restriction
Use Consistency Range NLGI NO. 00. 0. 1
Weight 7C 2.2kg、4C 2.1kg 2C 2.1kg、8P 3.3kg
3P 2.2kg |
